S-85 XC FE
Telescopic Boom Lift
The Genie S®-85 XC™ FE hybrid telescopic boom lift is an Xtra Capacity™ (XC), electrified telescopic boom – with no compromise on performance compared with a diesel unit, while opening the door to low-noise and low-emissions applications. The XC feature allows up to three people onboard along with tools and jobsite materials. The Genie S-85 XC FE Hybrid is the first 85 ft | 26 m boom lift to offer a lithium-powered generator-welder system (available as an option).
Overview
- Two modes of operation: electric and hybrid, with outstanding efficiency and jobsite versatility
- True rough terrain performance with 4WD, 45% gradeability and active oscillating axle
- Dual lift capacity of 660 lb (300 kg) unrestricted and 1,000 lb (454 kg) restricted
- Simplified maintenance with DPF-free engine and fully sealed AC electric drive motors
- Standard lithium-ion maintenance-free battery
- Work is possible even on dead batteries thanks to state-of-the-art hybrid technology, also offering regenerative braking and automatic start-and-stop
- Robust 5 ft (1.52 m) jib with a 133° working range for accurate positioning
- Optional: Genie Lift Power™ generator welder-ready system
- Optional: EVSE (electric vehicle charging port) for fast charging
| Specification | Value |
|---|---|
| Max Working Height | 91 ft | 27.91 m |
| Max Horizontal Reach | 74 ft 6 in | 22.71 m |
| Below Ground Reach | 8 ft 8 in | 2.64 m |
| Platform Capacity | 660 lb Unrestricted, 1,000 lb Restricted | 300 kg Unrestricted, 454 kg Restricted |
| Machine Width and Length | 8 ft 2 in, 41 ft 9 in | 2.49 m, 12.37 m |
- S-85 XC FE & S-85 XC E - Product Specifications - 2025 - EN-US
- To view earlier versions of this specification sheet, please click here and look up for your machine Operator Manual by serial number.
The relevant specification data will be on the last page.
